K80 - TORNADO PRINTER

ASK FOR INFORMATION
ABOUT THIS PRODUCT

80MM RECEIPT/TICKET PRINTER



  • 200dpi best printing quality
  • Paper width from 76 to 80mm
  • Paper roll (diameter 180mm on board)
  • RS232 and USB interface
  • 1D/ 2D barcodes printing capability (QRCODE)
  • International fonts on board: any language available
  • Highly reliable cutter
  • Sensors: Head temperature, paper presence, near paper end, black mark 6 position, ticket out



  • K80 - TORNADO PRINTER
  • EXCLUSIVE
    FEATURES
  •
  •
  • Ideal solution for ATM's VTM's & Self Service Kiosk

    • Ultra-compact
    • Heavy-duty alluminium printing engine
    • Anti-jamming system
    • Anti-instrusion shutter
    • Anti-splash paper exit
    • On/off switch
  •

    SOFTWARE CePrinterSet : to update logos,edit characters, set operating parameters and update the printer firmware. It allows you to create a file including the different SW customizations and send them to the printer via the interface provided, for easy and fast setting.



  • TECHNICAL FEATURES
  •
  •
  • Printing Method Thermal, fixed head
    Number of dots 8 dot/mm
    Resolution 203 dpi
    Printing (mm/sec) 150 mm/s
    Character set 54 character code tables
    Extended chinese GB18030-2000, Korean PC949

    Supported Barcode UPCA, UPCE, EAN13, EAN8, CODE39, ITF, CODABAR, CODE93, CODE128, CODE32, QRCODE
    Printing Format Height/Width from 1 to 8, bold, reverse, underlined, italic
    Printing Direction Normal, 90°, 180°, 270°
    Paper width 76, 80 ± 0,5 mm
    Paper weight from 55 g/m2 to 80 g/m2
    Paper thickness from 63 μm to 88 μm
    Printing width from 52 to 80mm
    Roll Dimension max 180 mm
    Sensors Head temperature, paper presence, near paper end, black mark, ticket out
    Emulation CUSTOM/POS
    Interfaces USB + RS232 Serial
    Data Buffer 8 Kbytes
    Flash Memory 768 Kbytes internal, 4 Mbytes external
    RAM Memory 128 Kbytes
    Graphic Memory 1 logo (640x409 dots)
    Drivers Windows XP
    VISTA (32/64bit)
    Windows 7 (32/64bit)
    Windows 8 (32/64bit)
    Windows 8.1 (32/64bit)
    Linux (32/64bit)

    Power supply 24 Vdc ±10% (optional external power supply)
    Medium consumption 0.8 A   (12,5% dots on)
    MTBF 165 245 hours (electronic board)
    Head Life 100 Km
    MCBF 1.000.000 cut
    Operating temperature from 0°C to +50°C
    Dimensions 258(L) x 103.5(H) x 135(W) mm
    Weight 1250 g
