APS MP105 |
|
| 产品名称：APS MP105 |
| 产品编号：APS MP105 |
| 详细说明： |
|
Features Ultra compact design (height only 13 mm and weight only 30 g) - 1 inch paper width - No loose wiring (a single flex-cable houses all wiring) - Ergonomic design (centered paper path allows uniform and aesthetic housing design) - High reliability in an extremely small size - Prints high quality characters at speed up to 80 mm/s - Foot print compatible with shuttle type
|
|
EFTs POS
Fiscal printers
Automotive
Medical equipments
Portable printers and terminals
Hand held terminals
Measuring Instruments and Analysers
Data terminal devices
Taxi meters
|
|
Printing method:
|
Thermal
|
|
Number of dots:
|
192
|
|
Resolution (dots/mm):
|
8
|
|
Printing width (mm):
|
24
|
|
Paper width (mm):
|
38
|
|
Max. paper thickness (um):
|
80
|
|
Paper loading:
|
Automatic
|
|
Printing speed (mm/s):
|
80
|
|
Paper detection:
|
Opto sensor
|
|
Temperature detection:
|
Thermistor
|
|
Head-up or Cover-open detection:
|
Not available
|
|
Voltage range (Logic/Head):
|
5 ± 5% / 4.2-8.5
|
|
Dot resistance (Ohm):
|
142 ± 4%
|
|
Energy per dot (mJ):
|
0.31
|
|
Stepper motor (Ohm):
|
Bipolar (20)
|
|
Weight (g):
|
30
|
|
Life/reliability:
|
50km/100M pulses
|
|
Operating temperature (C):
|
0 to 50 non cond.
|
|
Operating humidity (%):
|
20 to 85 non cond.
|
|
Dimensions (WxDxH mm):
|
48x32x13.8
|
|
 |
