| 型号 |
FTP-628MCL053/054 |
FTP-628MCL 101#50/103/#21 |
FTP-628MCL353/354 |
FTP-628MCL701 |
FTP-628MCL401 |
FTP-628WSL120 |
|
FTP-638MCL401 |
FTP-648MCL103 |
| 产品外观 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
| 特性 |
Auto Paper Loading Type |
Easy Paper Loading Type |
Auto Paper Loading Type With Cutter |
Veryical Easy Paper Losding Type |
Easy Paper Setting Type With Cutter |
Easy Paper Loading Type |
Easy Paper Loading Type |
Easy Paper Loading Type With Cutter |
Easy Paper Loading Type |
| 打印方式 |
Thermal sensitive line dot methhod |
Thermal sensitive line dot methhod |
Thermal sensitive line dot methhod |
Thermal sensitive line dot method |
Thermal sensitive line dot method |
Thermal sensitive line dot method |
Thermal sensitive line dot method |
Thermal sensitive line dot method |
Thermal sensitive line dot method |
| 每行点（点/行） |
384 |
384 |
384 |
384 |
384 |
384 |
576 |
576 |
832 |
| 分辨率（点/mm） |
8 |
8 |
8 |
8 |
8 |
8 |
8 |
8 |
8 |
| 每行字符数（字符/行） |
32 (12×24 dot)
|
32 (12×24 dot)
|
32 (12×24 dot)
|
32 (12×24 dot)
|
32 (12×24 dot)
|
32 (12×24 dot)
|
32 (12×24 dot)
|
48 (12×24 dot)
|
69 (12×24 dot)
|
| 有效打印宽度（mm） |
48 |
48 |
48 |
48 |
48 |
48 |
64 |
72 |
104 |
| 最大打印速度（mm/s) |
80 |
80 |
80 |
80 |
80 |
80 |
80 |
80 |
50 |
| 进纸步距（mm） |
0.125 |
0.125 |
0.125 |
0.125 |
0.125 |
0.125 |
0.125 |
0.125 |
0.125 |
| 驱动电压（V) |
Head/Motor:4.2 to 8.5 Logic/ :3.0 to 5.25 |
Head/Motor:4.2 to 8.5 Logic/Cutter:3.0 to 5.25 |
Head/Motor:4.2 to 8.5 Logic/ :3.0 to 5.25 |
Head/Motor:4.2 to 8.5 Logic/Cutter:3.0 to 5.25 |
Head/Motor:4.2 to 8.5 Logic/Cutter:3.0 to 5.25 |
3.7VCD lithium ion battery |
Head/Motor:4.2 to 8.5 Logic/ :3.0 to 5.25 |
Head/Motor:4.2 to 8.5 Logic/ :3.0 to 5.25 |
Head/Motor:4.2 to 8.5 Logic/ :2.7 to 5.25 |
| 尺寸（mm) |
69.6W×34.3L×15.5H |
70.3W×33L×15.5H |
80.5W×43L×26.4H |
70.3W×33L×15.5H |
81.2W×42.2L×21.8H |
84W×134.5L×43.6H |
92.3W×33L×15.5H |
103.2W×42.2L×21.8H |
138.3W×40.5L×20.5H |
| 重量（g） |
47 |
46 |
120 |
46 |
97 |
280 |
53 |
118 |
148 |
| 寿命（脉冲，磨损） |
1×108 pulses 50km |
1×108 pulses 50km |
1×108 pulses 50km 3×105 cuts |
1×108 pulses 50km |
1×108 pulses 50km 5×105 cuts |
1×108 pulses 50km |
1×108 pulses 50km |
1×108 pulses 50km |
1×108 pulses 50km |
| 适用纸宽（mm） |
58 |
58 |
58 |
58 |
58 |
58 |
80 |
80 |
112 |
