CAP9347E-S640-E

CAP9347E-S640-E
产品名称:CAP9347E-S640-E
产品编号:CAP9347E-S640-E
详细说明:

CAP9000 Series Product Specifications

Model CAP9247 CAP9347
Printing Method Thermal line dot printing
Number of dots/line 448 640
Resolution (dots/mm) 8
Paper width (mm) 58+-/ 60+- 80+- / 82.55+-
Printing width (mm) 54/56 76/80
Speed (max mm/sec) 250
Paper path Curved / Straight
Sensors Head temperature By thermistor
Out of paper detection By photo interrupter
Mark position detection By photo interrupter
Platen position detection By mechanical switch
Cutter position detection By mechanical switch
Power supply (V) Operation voltage (Vdd) 4.75 to 5.25
Operation voltage (Vp) 21.6 to 26.4
Peak current (A) Head 5.9 (26.4V / 128 dots)
Motor 1.0
Cutting Method Slide type
Paper thickness (μm) 57 to 155*
Cutting type Full cut / Partial cut (Leave center point)
Operating time (max sec/cycle) 2
Cutting pitch (min mm) 10
Cut frequency (max cuts/min) 30
Service life Pulse activation 150 million
Abrasion resistance (km) 150*
Auto-cutter (cuts) 1 million
Operating temperature (°C) -20 to 60
Dimensions (W x D x H mm) 89.5 X 50.0 X 30.0** 112.0 X 50.0 X 30.0**
Mass(g) Approx.240 Approx.290

LTP9000 Series Product Specifications

Model LTP9247 LTP9347 LTP9447
Printing Method Thermal line dot printing
Number of dots/line 448 640 832
Resolution (dots/mm) 8
Paper width (mm) 58+-/ 60+- 80+- / 82.55+- 112+-
Printing width (mm) 54/56 76/80 104
Speed (max mm/sec) 250
Paper path Curved / Straight
Sensors Head temperature By thermistor
Out of paper detection By photo interrupter
Mark position detection By photo interrupter
Platen position detection By mechanical switch
Cutter position detection
Power supply (V) Operation voltage (Vdd) 4.75 to 5.25
Operation voltage (Vp) 21.6 to 26.4
Peak current (A) Head 5.9 (26.4V / 128 dots)
Motor 1.0
Cutting Method
Paper thickness (μm)
Cutting type
Operating time (max sec/cycle)
Cutting pitch (min mm)
Cut frequency (max cuts/min)
Service life Pulse activation 150 million
Abrasion resistance (km) 150*
Auto-cutter (cuts) 1 million
Operating temperature (°C) -20 to 60
Dimensions (W x D x H mm) 88.8 X 50.0 X 29.7** 111.25 X 50.0 X 29.7** 140.75 X 57.5 X 29.7**
Mass(g) Approx.150 Approx.180 Approx.240
* Use recommended thermal papers
** Excluding protrusion


IF9001-01U USB interface board
     IF9001-01U


IF9001-01S serial interface board
     IF9001-01S


IF9001-01P parallel interface board
    IF9001-01P


Interface Board

Model IF9001-01U IF9001-01S IF9001-01P
CPU IF9001 only
Thermal printer CAP9247, CAP9347
Operating voltage (V) Vp: 21.6 to 26.4
Character matrix (H x W dots) 16 dots characters: 16 X 8, 16 X 16
24 dots characters: 24 X 12, 24 X 24
Character type Optional font Yes Yes Yes
Downloaded character Yes Yes Yes
User-defined character Yes Yes Yes
Extend graphics character set Yes Yes Yes
Katakana character set Yes Yes Yes
JIS 1&2 level Kanji Yes Yes Yes
Interface USB Serial (RS-232C) Parallel
Dimensions (W x D x H mm) 108.0 X 90.0 X 28.0
