9 Pin Parallel Bidirectional Printing POS76 76MM printer pos printer

9 Pin Parallel Bidirectional Printing  POS76 76MM printer pos printer
Product name:9 Pin Parallel Bidirectional Printing POS76 76MM printer pos printer
Item:九针列式双向打印 POS76 76MM printer pos printer 热敏打印机九针列式
Details:



Product Name: POS76III
Product Details

Feature:


Versatile and adaptable
Easy to use and simple to maintain
Complete compatibility with EPSON

Specification


Print
Printing Method
9 Pin Parallel Bidirectional Printing
Printing Speed
7.1 line/sec at 16CPL
4.1 line/sec at 40CPL
4  line/sec at 42CPL
Printing Density
42cpl-210(Full dot)/420(half dot)
40cpl-200(Full dot)/400(half dot)
Effective Printing Width
42cpl-42(77)/35(57)
40cpl-40(77)/33(57)
Character
IBM Character Set

7x7 dot or 5 x7 dot

International Standard I、II Class Chinese Font
24×24dot3.00(width)×3.00(height)mm
Paper Spec
Paper Type
Normal paper/Pressure-sensitive paper
Paper Width
76mm±0.5mm
Paper Roll Diameter
Max:80mm
Roll Core Inner Diameter
 10mm(min.)
Paper Thickness
Normal paper:1 sheet 0.06mm to 0.085 mm
Pressure-sensitive paper: 0.05 to 0.08 mm {0.002 to 0.0031”} (thickness of one sheet);combined, total thickness must be 0.2 mm {0.008”} or less
Reliability
MCBF
900million lines
Auto Cutter
10million cuts
Emulation
ESC/POS
Driver
Win 2000/2003/XP/Vista/Win 7
Sensor
Paper End Sensor
Drawer Port
1 Port
Interface
RS-232, Parallel, USB
Power Supply (Adapter)
DC 24V, 2A
Auto cutter
Type
Sliding type
Life
10million cuts
Cutting Method
Full / Manual
Physical
Net Weight
2kg(without paper roll)
Gross Weight
3.41kg
Printer Dimension
195(L) x 138(W)x 150(H) mm
Color
White/Black
