FTP-639MCL383#02 PRINTER HEAD AUTO CUTTER   FTP-639MCL103/383


Fujitsu High Speed ELM Thermal Printer
FTP-629MCL383
FTP-639MCL383
Product Specification
􀂧 Printer type FTP-629MCL383#01 FTP-629MCL383#02 FTP-639MCL383#01 FTP-639MCL383#02
􀂧 Operating power 24VDC 24VDC 24VDC 24VDC
􀂧 Current peak approx. 4,0A approx. 4,0A approx. 4,0A approx. 4,0A
􀂧 Paper insertion easy loading easy loading easy loading easy loading
􀂧Paper width 58mm 58mm 80mm 80mm
􀂧Eff. printing width 54mm 54mm 72mm 72mm
􀂧 Printing speed 200mm/sec. 200mm/sec. 200mm/sec. 200mm/sec.
􀂧Paper thickness 80-120ym 80-120ym 80-120ym 80-120ym
􀂧 Operating temp. -20°C to +60°C -20°C to +60°C -20°C to +60°C -20°C to +60°C
􀂧 Storage temp. -20°C to +60°C -20°C to +60°C -20°C to +60°C -20°C to +60°C
􀂧Head life 50km 50km 50km 50km
􀂧 Head configuration 432dots/line 432dots/line 576dots/line 576dots/line
􀂧 Cutter life time 500.000 cuts 500.000 cuts 500.000 cuts 500.000 cuts
􀂧 Cutting type full cut partial cut full cut partial cut
􀂧 Mech. dim. (WxDxH) 90,5x70,3x37,4mm 90,5x70,3x37,4mm 112,5x70,3x37,4mm 112,5x70,3x37,4mm
􀂧 Paper detection, head up detection, black mark detection, head temperature detection
􀂧 RS232/USB interface board available
