| Printing Method |
Shuttle impact dot matrix |
| Printing Format |
| Font |
5 x 7 |
| Column capacity |
M-190: 24 columns
M-191: 32 columns
M-192: 40 columns
M-195: 18 columns |
| Character size |
M-190: 1.7 (W) x 2.6 (H)mm
M-191: 1.3 (W) x 2.6 (H)mm
M-192: 1.1 (W) x 2.6 (H)mm
M-195: 1.7 (W) x 2.6 (H)mm |
| Line spacing |
3.7mm (In case of 5 x 7 and 3 dots / line paper feed) |
| Column spacing |
M-190: 2.0mm
M-191: 1.5mm
M-192: 1.2mm
M-195: 2.0mm |
| Number of total dots |
M-190: 144 dots / line
M-191: 192 dots / line
M-192: 240 dots / line
M-195: 108 dots / line |
| Printing Speed |
M-190: 2.5 line / sec.
M-191: 1.9 line / sec.
M-192: 1.5 line / sec.
M-195: 2.5 line / sec. |
| Printhead |
| Terminal Voltage |
3.3 to 5.2 VDC |
| Peak current |
Approx. typ 2.5 A / solenoid |
| Motor |
| Terminal Voltage |
3.8 to 5.2 VDC (3.8 to 5.5 VDC by Ni-Cd battery) |
| Mean current |
Approx. 0.35 A |
| Paper |
| Dimensions |
M-190/M-191/M-192: 57.5 ± 0.5mm (W) x dia. 83mm maximum
M-195: 44.5 ± 0.5mm |
| Total Thickness |
0.06 to 0.085mm |
| Copy Capability |
Original + one copy |
| Ribbon Cassette |
ERC-09/22 |
| Ambient Temperature |
0° to 50°C (operating) |
| Reliability |
| Mechanism (MCBF) |
M-190: 1.5 x 106 lines
M-191: 1.1 x 106 lines
M-192: 0.9 x 106 lines
M-195: 1.5 x 106 lines |
| Printhead Life |
M-190: 1.5 x 106 lines
M-191: 1.1 x 106 lines
M-192: 0.9 x 106 lines
M-195: 1.5 x 106 lines |
| Overall Dimensions |
91.0 (W) x 46.9 (D) x 15.8 (H) mm |
| Weight |
Approx. 100g |
