Specifications

• Printing method:
• Thermal

• Number of dots:
• 384

• Resolution (dots/mm):
• 8

• Printing width (mm):
• 48

• Paper width (mm):
• 58

• Max. paper thickness (um):
• 80

• Paper loading:
• Easy loading

• Printing speed (mm/s):
• 50

• Paper detection:
• Opto sensor

• Temperature detection:
• Thermistor

• Head-up or Cover-open detection:
• Opto sensor

• Voltage range (Logic | Head):
• single 3-7.2 V

• Dot resistance (Ohm):
• 116 ± 10%

• Stepper motor (Ohm):
• Bipolar (12)

• Weight (g):
• 80

• Life/reliability:
• 50km/ 100M pulses

• Operating temperature (°C):
• -5 to +50

• Operating humidity (%):
• 20 to 85 non cond.

• Dimensions (WxDxH mm):
• 76.8x77.4x45

• Cutter:
• Tear bar

• Paper roll diam. max. (mm):
• 32

Controller board

• Expanded Flash memory:
• No

• Expanded RAM memory:
• no

• PCMCIA slots:
• No

• Character set:
• 3

• Character size:
• 9 x 20, 13 x 24, 8 x 16

• Characters per line (max.):
• 48

• Interfaces:
• RS232, TTL. Centronics

• Graphics:
• 5 modes

• Barcodes:
• UPCA-E, EAN 13-8, Code 39, ITF 2/5, Codabar, Code

• Windows drivers:
• 95 / 98 / ME / XP / NT / 2000

• Label/Black mark detection:
• Yes

• Zero power mode (sleep mode):
• Yes

• Auto wake-up on received data:
• Yes

• Functional keyboard:
• Yes
